Chapter 3- Understanding the Robotic Mower
Thank you for purchasing our Robotic Mower. Over the next few pages, the Robotic Mower will be explained
in further detail considering the operation
pr ocedur e.
3.1 Packaging contents
Please inspect all packaging contents as follows:
Fig.1
1. Robotic Mower
12. Blades (3 pcs+3pcs)
2. LCD display cover
13 Blade disk
3. Stop button
14. Rain sensor
4. Cover for height adjust knob
15. Charger
5. LCD display & keyboard
16. Fixing peg (for boundary wire)
6. Height adjustment knob
17. Fixing nail (for charging station)
7. Main power switch
18. Measurement ruler
8. Front wheel
19. Charging pin
9. Battery cover
20. Charging station / Base station
10. Rear wheel
21. Boundary wire
11. Carrying handle
22. Base plate bumper
