NPort 6000 Series Configuration with the Web Console
Web Console Navigation
On the NPort 6000 web console, the left panel is the navigation panel and contains an expandable menu tree
for navigating among the various settings and categories. When you click on a menu item in the navigation
panel, the main window will display the corresponding options for that item. Configuration changes can then be
made in the main window. For example, if you click on Network Configurations in the navigation panel, the
main window will show a page of network-related settings that you can configure.
You must click on the Submit button to keep your configuration changes. The Submit button will be located
at the bottom of every page that has configurable settings. If you navigate to another page without clicking the
Submit button, your settings will not be retained.
Changes will not take effect until they are saved and the NPort is restarted! You may complete this in
one step by clicking on the Save/Restart option after you submit a change. If you need to make several
changes before restarting, you may save your changes without restarting by selecting Save Configuration in
the navigation panel. If you restart the NPort 6000 without saving your configuration, the NPort 6000 will
discard all submitted changes.
Network Configuration
Basic Network Settings
You can access Basic Network Settings by expanding the Network Configuration item in the navigation
panel. Basic Network Settings is where you assign the NPort 6000 IP address, netmask, Gateway, and other IP
parameters.
You must assign a valid IP address to your NPort 6000 before it will work in your network environment. Your
network system administrator should provide you with a unique IP a
ddress and related settings for your
-time users can refer to Chapter 3, Initial IP Address Configuration, for more information.
