4-45. PARTS LIST Table 4-1. Parts List
DRIVE END SIZE
REF.
NO. DESCRIPTION E F G H J K
1 Radial Grease Seal ................................ AG0611 PF0611 PG0611 PH0611 PJ0611 PK0611
2 Bearing Cover Plate ............................... PE0341 PF0341 PG0341 PH0341 PJ0341 PK0341
3 O-Ring.................................................... PE110Q BJ112Q BK113Q PH110Q BH114Q PK110Q
4 Drive Shaft Head .................................... PE0971 PF0971 PG0971 PH0971 PJ0971 PK0971
5 O-Ring Shaft Head: ................................ BE111Q BE113Q BG114Q BH111Q TJ111Q BK114Q
6 Primary Thrust Plate............................... PE0981 PF0981 PG0981 PH0981 PJ0981 PK0981
7 Key ......................................................... RE0761 RF0761 RG0761 RH0761 RJ0761 RK0761
8 Ring Gear............................................... AE0952 AF0952 AG0952 AH0952 AJ0952 AK0952
9 Lock Nut ................................................. RE0581 RF0581 RG0581 RH0581 RJ0581 RK0581
10 Gear Ball................................................. AE0951 AF0951 AG0951 AH0951 AJ0951 AK0951
Gear Joint Kit (See Note C).................... KPE951 KPF951 KPG951 KPH951 KPJ951 KPK951
11 Secondary Thrust Plate.......................... PE0982 PF0982 PG0982 PH0982 PJ0982 PK0982
12 Seal Support........................................... PE0891 PF0891 PG0891 PH0891 PJ0891 PK0891
13 Gear Joint Seal:
CDQ, CSQ, SSQ, CDR, CSR, SSR.... PE087Q PF087Q PG087Q PH087Q PJ087Q PK087Q
CDB, CSB, SSB, CDF, CSF, SSF ...... PE087F PF087F PG087F PH087F PJ087F PK087F
Gear Joint Seal Kit (See Note D):
CDQ, CSQ, SSQ, CDR, CSR, SSR .... KPE87Q KPF87Q KPG87Q KPH87Q KPJ87Q KPK87Q
CDB, CSB, SSB, CDF, CSF, SSF ...... KPE87F KPF87F KPG87F KPH87F KPJ87F KPK87F
14 Drive Shaft:
CDQ, CDR, CDB, CDF ....................... PE0261 PF0261 PG0261 PH0261 PJ0261 PK0261
CSQ, CSR, CSB, CSF,
SSQ, SSR, SSB, SSF......................... PE0266 PF0266 PG0266 PH0266 PJ0266 PK0266
15 Tapered Roller Bearing........................... PE0311 PF0311 PG0311 PH0311 PJ0311 PK0311
Bearing Kit (See Note B) ........................ KPE291 KPF291 KPG291 KPH291 KPJ291 KPK291
16 Bearing Spacer....................................... PE0331 PF0331 PG0331 PH0331 PJ0331 PK0331
17 Bearing Lock Plug .................................. P10762 P10762 P10762 P10762 P10762 P10762
18 Bearing Lock Nut.................................... PE0581 PF0581 PG0581 PH0581 PJ0581 PK0581
19 Thrust Grease Seal ................................ AK0621 XK0621 PG0621 PH0621 Al4611 PK0621
20 Slinger Ring............................................ PE0771 PF0771 PG0771 PH0771 PJ0771 PK0771
21 Packing Gland Half (See Note A):
CDQ, CDR, CDB, CDF,
CSQ, CSR, CSB, CSF ........................ PE041D PF041D PG041D PH041D PJ041D PK041D
SSQ, SSR, SSB, SSF......................... PE041S PF041S PG041S PH041S PJ041S PK041S
22 Packing (See Note A)............................. PE0423 PF0423 PG0423 PH0423 PJ0423 PK0423
23 Lantern Ring Half (See Note A).............. AE0571 PF0571 PG0571 PH0571 AJ0571 PK0571
24A Adapter Gasket:
CDB, CSB, SSB.................................. ----- BF085B BG085B BH085B ----- BK085B
CDQ, CDR, CSQ, CSR, SSQ, SSR.... ----- BF085Q BG085Q BH085Q ----- BK085Q
CDF, CSF, SSF .................................. ----- BF085F BG085F BH085F ----- BK085F
24B Adapter Gasket:
CDB, CSB, SSB.................................. ----- ----- ----- ----- BK085B -----
CDQ, CDR, CSQ, CSR, SSQ, SSR .... ----- ----- ----- ----- BK0B5Q -----
CDF,CSF,SSF .................................... ----- ----- ----- ----- BK085F -----
25A Adapter Bushing—See Tables 4-2 and 4-3
25B Adapter Bushing—See Tables 4-2 and 4-3
26 Bearing Housing..................................... PE0051 PF0051 PG0051 PH0051 PJ0051 PK0051
27 Retaining Ring........................................ AF0085 AG0085 PG0085 AH0085 PJ0085 PK0085
28 Clamp Ring............................................. AF0932 AG0932 PG0932 AH0932 PJ0932 PK0932
29 Suction Housing—See Tables 4-2 and 4-3
30 Stator—See Table 4-4
31 Stator Support—See Tables 4-2 and 4-3
32 Inspection Plate:
CDQ, CDR, CDB, CDF,
CSQ, CSR, CSB, CSF ........................ BE0171 BF0171 BF0171 BF0171 BH0171 BJ0171
SSQ, SSR, SSB, SSF......................... BE0176 BF0176 BF0176 BF0176 BH0176 BJ0176
-K800 CDQ, CDR, CDB, CDF,
CSQ, CSR, CSB, CSF................. ----- ----- ----- ----- ----- BJ0172
SSQ, SSR, SSB, SSF.................. ----- ----- ----- ----- ----- BJ0177
33 Inspection Plate Gasket:
CDB, CSB, SSB.................................. BE079B BF079B BF079B BF079B BH079B BJ079B
CDQ, CDR, CSQ, CSR, SSQ, SSR.... BE079Q BF079Q BF079Q BF079Q BH079Q BH079Q
CDF, CSF, SSF .................................. BE079F BF079F BF079F BF079F BH079F BH079F
34 Stator Gasket—See Table 4-5
35 Retaining Ring—See Tables 4-2 and 4-3
Part List Continued on Page 16.
Page 15
