Page 22
SEE PG. 23 FOR EXPLODED VIEW OF PUMP
Table 4-13. Shaft Sleeve Arrangement
REF. NO: 43 22A 23A 21A 29A
SHAFT SLEEVE KIT* PACKING LANTERN PACKING SUCTION
RING HALF GLAND HOUSING
HALF
CDO,CSR CDB CDF
CDR, SSQ CSB CSF ALL ALL CD CD
CSQ, SSR SSB SSF MODELS MODELS CS SS CS SS
MODEL
E008, E012, E018E KE003Q KE003B KE003F PF0423 PF0571 PE042D PE042S PE0024 PE0029
E022, E033E KE003Q KE003B KE003F PF0423 PF0571 PE042D PE042S PE0028 PE0030
E036, E050 KE003Q KE003B KE003F PF0423 PF0571 PE042D PE042S PE0033 PE0034
F012, F022, F033E KF003Q KF003B KF003F PF1423 PF1571 PF042D PF042S PF0024 PF0029
F036, F050, F054E KF003Q KF003B KF003F PF1423 PF1571 PF042D PF042S PF0028 PF0030
F065, F090 KF003Q KF003B KF003F PF1423 PF1571 PF042D PF042S PF0033 PF0034
G022, G036, G050,
G054E, G075E
KG003Q HG003B KG003F PH0423 PH0571 PG042D PG042S PG0024 PG0029
G065, G090, G098E KG003Q KG003B KG003F PH0423 PH0571 PG042D PG042S PG0028 PG0030
G115 KG003Q KG003B KG003F PH0423 PH0571 PG042D PG042S PG0033 PG0034
H036, H065, H090, H115 KH003Q KH003B KH003F PH1423 PH1571 PH042D PH042S PH0024 PH0029
H175 KH003Q KH003B KH003F PH1423 PH1571 PH042D PH042S PH0033 PH0034
J065, J090, J115 KJ003Q KJ003B KJ003F PJ1423 PJ1571 PJ042D PJ042S PJ0024 PJ0029
J175, J335 KJ003Q KJ003B KJ003F PJ1423 PJ1571 PJ042D PJ042S PJ0028 PJ0030
J345 KJ003Q KJ003B KJ003F PJ1423 PJ1571 PJ042D PJ042S PJ0033 PJ0034
K115, K175, K335 KK003Q KK003B KK003F PK1423 PK1571 PK042D PK042S PK0024 PK0029
K345, K620
K800 KK003Q KK003B KK003F PK1423 PK1571 PK042D PK042S PK0030 PK0031
*Kit includes Shaft Sleeve (Ref. No. 45), Set Screws (Ref. No. 46), and 2 O-Rings (Ref. No. 44).
Table 4.14. Shaft Sleeve Conversion Kit**
CDQ
CDR
CDF CDB CSQ, SSQ
CSR, SSR
CSB
SSB
CSF
SSF
MODEL
E KE009Q KE009F KE009B KE015Q KE015B KE015F
F KF009Q KF009F KF009B KF015Q KF015B KF015F
G KG009Q KG009F KG009B KG015Q KG015B KG015F
H KH009Q KH009F KH009B KH015Q KH015B KH015F
J KJ009Q KJ009F KJ009B KJ015Q KJ015B KJ015F
* *Kit includes Shaft Sleeve Kit (Ref. No. 43), Packing (Ref. No. 22A), 2 Lantern Ring Halves (Ref. No. 23A), and 2 Packing Gland
Halves (Ref. No. 21A).
