C U S E R I E S Installation, Operating & Maintenance Manual
SELECT A MR. STEAM CU SERIES GENERATOR
The resultant calculated volume of the steam room determines
the Model CU steambath generator required. Steam room size
and additional constructional factors affect model selected.
A.
To determine the steam room volume first multiply
L
ength x Width x Height of the steam room
__________________________________________________
Example: A steam room 8' x 9' x 8' = 576 cu. ft. (volume).
Select the Mr. Steam Model which is the next larger volume.
In this example, Model CU-750 is the correct selection.
Example: 2 Steam rooms each 6' x 10' x 7' x 2 rooms = 840 cu. ft.
(volume). In this example, Model CU-1000 is the correct selection.
NOTE:
Insure adequate consideration is given to assure that
the CU unit selected is not undersized for the room.
Increase volume if the piping runs longer than 25 feet from the
generator to steam room.
B. IMPORTANT:
The selection guidelines are recommendations only.
Always consult with contractor, designer or architect.
For general information, contact East Coast: 1-800-767-8326 or
West Coast: 1-800-727-8326.
Model Max Room Water Inlet Generator Outlet Dimensions
(inches)
Shipping
No. KW Volume* (cu ft) Size NPT Size, NPT WL H Wt. (lbs.)
CU-360 9 400 1/4" 1" 20 30 38 250
CU-500 12 500 1/4" 1" 20 30 38 250
CU-750 18 750 1/4" 1" 20 30 38 250
CU-1000 24 1000 1/4" 1" 20 30 38 270
CU-1250 30 1250 1/4" 1" 20 30 38 290
CU-1400 36 1400 1/4" 1" 20 30 38 300
CU-2000 48 2000 1/2" 1" 24 33 44 330
CU-2500 60 2500 1/2" 1" 24 33 44 380
CU-3000 72 3000 1/2" 1" 24 33 44 390
CU-4500 108 4500 1/2" 1-1/2" 28 34 59 625
C. IMPORTANT:
When specifying a CU Commercial Steambath
generator the following is strongly recommended for best
performance and user satisfaction.
1. One CU steambath generator should service no more that two
(2) steam rooms, each relatively similar in size and construction.
2. If two (2) steam rooms are serviced by one (1) CU generator,
the combined resultant room volume of the two rooms should
not exceed 1000 cubic feet.
3. Each room must be operated with the appropriate Digital 1
temperature control system inclusive of the room operating
temperature control and the high-limit temperature control.
4. In any case, the purchaser and/or owner/
operator must consult with a designer,
architect, and/or consultant to assure the
proper specification of the steam generator.
*After taking into consideration all factors affecting resultant steam room volume including length,
width & height of steam room and distance to generator, select proper Model CU generator.
Consult with an architect, engineer, designer and/or contractor before making final selection.
