MSA BD mini - Technical Data

DESCRIPTION MSA
8 BD mini
GB
2.4. Technical Data
High pressure
connection
: 200 bar resp. 300 bar
Medium pressure : 6 bar to 8 bar
Operating
temperature
: -30°C to +60°C
Activating pressure of
warning signal
:
from 1055 bar to 555 bar
Weight (approx.) : 2.1 kg
Dimensions (approx.) : Length 420 mm
Width 240 mm
Height 105 mm
Approvals :
The compressed air breathing apparatus conforms
to the Directives 89/686/EEC and 94/9/EG. It is a
container unit with compressed air in accordance
with EN 137:2006 Typ 2.
0158
ATEX
BVS 10 ATEX H 011 X
IM 1
II 1 GD IIC 85°C (T6) -40°C ≤ Ta ≤ +60°C
II 1D
