10.9 A Bank DIP Switch Settings
Address A0 A1 A2 A3 A4 A5 A6 A7 Address A0 A1 A2 A3 A4 A5 A6 A7
1 On Off Off Off Off Off Off Off 46 Off On On On Off On Off Off
2 Off On Off Off Off Off Off Off 47 On On On On Off On Off Off
3 On On Off Off Off Off Off Off 48 Off Off Off Off On On Off Off
4 Off Off On Off Off Off Off Off 49 On Off Off Off On On Off Off
5 On Off On Off Off Off Off Off 50 Off On Off Off On On Off Off
6 Off On On Off Off Off Off Off 51 On On Off Off On On Off Off
7 On On On Off Off Off Off Off 52 Off Off On Off On On Off Off
8 Off Off Off On Off Off Off Off 53 On Off On Off On On Off Off
9 On Off Off On Off Off Off Off 54 Off On On Off On On Off Off
10 Off On Off On Off Off Off Off 55 On On On Off On On Off Off
11 On On Off On Off Off Off Off 56 Off Off Off On On On Off Off
12 Off Off On On Off Off Off Off 57 On Off Off On On On Off Off
13 On Off On On Off Off Off Off 58 Off On Off On On On Off Off
14 Off On On On Off Off Off Off 59 On On Off On On On Off Off
15 On On On On Off Off Off Off 60 Off Off On On On On Off Off
16 Off Off Off Off On Off Off Off 61 On Off On On On On Off Off
17 On Off Off Off On Off Off Off 62 Off On On On On On Off Off
18 Off On Off Off On Off Off Off 63 On On On On On On Off Off
19 On On Off Off On Off Off Off 64 Off Off Off Off Off Off On Off
20 Off Off On Off On Off Off Off 65 On Off Off Off Off Off On Off
21 On Off On Off On Off Off Off 66 Off On Off Off Off Off On Off
22 Off On On Off On Off Off Off 67 On On Off Off Off Off On Off
23 On On On Off On Off Off Off 68 Off Off On Off Off Off On Off
24 Off Off Off On On Off Off Off 69 On Off On Off Off Off On Off
25 On Off Off On On Off Off Off 70 Off On On Off Off Off On Off
26 Off On Off On On Off Off Off 71 On On On Off Off Off On Off
27 On On Off On On Off Off Off 72 Off Off Off On Off Off On Off
28 Off Off On On On Off Off Off 73 On Off Off On Off Off On Off
29 On Off On On On Off Off Off 74 Off On Off On Off Off On Off
30 Off On On On On Off Off Off 75 On On Off On Off Off On Off
31 On On On On On Off Off Off 76 Off Off On On Off Off On Off
32 Off Off Off Off Off On Off Off 77 On Off On On Off Off On Off
33 On Off Off Off Off On Off Off 78 Off On On On Off Off On Off
34 Off On Off Off Off On Off Off 79 On On On On Off Off On Off
35 On On Off Off Off On Off Off 80 Off Off Off Off On Off On Off
36 Off Off On Off Off On Off Off 81 On Off Off Off On Off On Off
37 On Off On Off Off On Off Off 82 Off On Off Off On Off On Off
38 Off On On Off Off On Off Off 83 On On Off Off On Off On Off
42 ProtoNode Start-up Guide
