3-12
MS-6702E ATX Mainboard
Suspend Time Out (Minute)
After the selected period of system inactivity, all devices except the CPU shut off.
Settings: [Disabled], [1], [2], [4], [8], [10], [20], [30], [40], [50], [60].
Power Button Function
This feature sets the function of the power button. Settings are:
[Power Off] The power button functions as a normal power on/off button.
[Suspend] When you press the power button, the computer enters
the suspend/sleep mode, but if the button is pressed for
more than four seconds, the computer is turned off.
Restore On AC Power Loss
This setting specifies whether your system will reboot after a power failure or
interrupt occurs. Available settings are:
[Off] Always leaves the computer in the power off state.
[On] Always leaves the computer in the power on state.
[Last State] Restores the system to the previous status before power
failure or interrupt occurred.
Set WakeUp Events
Press <Enter> and the following sub-menu appears.
USB Wakeup From S3
This item allows the activity of the USB device to wake up the system from S3
(Suspend to RAM) sleep state. Settings: [Enabled], [Disabled].
Wake Up by Keyboard (with “Wake-Up Key” and “Wake-Up
Password”), Wake Up by PS/2 Mouse
These fields specify whether the system will be awakened from power saving
modes when activity or input signal of the specified hardware peripheral or
component is detected. Settings: [Enabled], [Disabled].
MSI Reminds You...
For “Wake-Up Key” function, the option “Specific Key” refers to the pass-
word you specify in the “Wake-Up Password” field. Once you set up a
password, it will disable “Wake up by PS/2 Mouse”.
