MS-6702E ATX Mainboard
5-14
Once the installation is complete, go to Start ---> Programs --->VIA ---> RAID --->
raid_tool.exe to enable VIA RAID Tool.
After the software is finished installation, it will automatically
start whenever Windows is initiated. You may double-click
on the icon shown in the system tray of the tool bar to
launch the VIA RAID Tool utility.
Using VIA RAID Tool
The main interface is divided into two windows and the toolbar above contain the main
functions. Click on these toolbar buttons to execute their specific functions. The left
windowpane displays the controller and disk drives and the right windowpane displays
the details of the controller or disk drives. The available features are as following:
View by Controller
View Event log
View by Devices
Help Topics
