19
Suite du tableau sur la page précédente
Fonctions LED
2 x connecteurs LED RGB à 4 broches
2 x connecteurs LED A-RAINBOW V2 (ARGB Gen2) à 3
broches
4 x EZ Debug LED
Connecteurs sur le
panneau arrière
1 x bouton Flash BIOS
1 x DisplayPort
1 x port HDMI™
4 x ports USB 3.2 Gen 1 5 Gb/s Type-A (depuis ASM1074)
3 x ports USB 3.2 Gen 2 10 Gb/s Type-A (depuis CPU)
1 x port USB 3.2 Gen 2x2 20 Gb/s Type-C (depuis chipset
B650)
1 x port LAN (RJ45) 2,5 Gb/s
2 x connecteurs d’antenne Wi-Fi
5 x prises audio
1 x connecteur de sortie S/PDIF optique
Contrôleur E/S Contrôleur NUVOTON NCT6687R
Moniteur système
Détection de la température CPU/Système/Chipset
Détection de la vitesse du ventilateur CPU/Système/
Pompe
Contrôle de la vitesse du ventilateur CPU/Système/Pompe
Dimensions
Format Micro-ATX
244 mm x 244 mm (9,6” x 9,6”)
Fonctions BIOS
1 x flash 256 Mb
UEFI AMI BIOS
ACPI 6.4, SMBIOS 3.5
Multilingue
Logiciel
MSI Center
MSI App Player (BlueStacks)
CPU-Z MSI GAMING
Norton 360 Deluxe
AIDA64 Extreme - MSI Edition
