MSI Media Live - System Configuration; Front Panel

1-4
MS-6421 Media Center
Front Panel
1. Microphone (Pink) 9. Rew Button
2. USB 2.0 Port 10. Fwd Button
3. IEEE 1394 Port 11. Skip Button
4. USB 2.0 Port 12. On / Standby
5. Headphone (Green) 13. Eject Button (for ODD)
6. Stop Button 14. Slim Slot-In Optical Disk Drive
7. Play Button 15. Memory Card Reader Drive
8. Replay Button 16. Integrated VFD Module
System Configuration
