MSI Media Live - Component Installation Procedures

3-4
MS-6421 Media Center
Installation Procedures
Unlock the four screws (screw type 1)
on the back panel with a screwdriver.
Follow the direction arrows to slide the
top cover off and then remove it by lift it
up carefully with hands.
After disassembly.
1. Removing Top Cover
1 2
3 4
Pull forward
Back Panel
