MSI Media Live - Chassis Design

1-6
MS-6421 Media Center
Chassis Design
- Dimension: 320mm (D) x 430mm (W) x 80mm (H) (with Bezel)
- 3.5" Memory Card Reader with four slots supports MS(MS-Pro), CF/MD
(CompactFlash I/II / Micro drive), SD/MMC, SM(SmartMedia)
- Minimized screw structure
- Detachable bay housing
- Multiple ventilation holes
1.System Ventilation Hole(for ODD) 4.System Ventilation Hole(for HDD)
2.Power Supply Fan Ventilation Hole 5.System Ventilation Hole(for HDD)
3.CPU Fan Ventilation Hole 6.System Ventilation Hole(for HDD)
Back
Side
Bottom
