MSI Media Live - Installing PCI Card

3-11
System Assembly
4. Installing PCI Card
Unlock the screw (screw type 1) on the
lock bracket with a screwdriver.
Remove the iron shield to release the
PCI expansion slot.
Follow the direction arrow to open the
lock bracket with fingers carefully.
