3-2
MS-6421 Media Center
Overview
Installation Screws
Two types of screws are used in assembling the MediaLive:
Both screw type 1 and screw type 2 are silver colours.
Screw type 1
This screw is used to lock the ODD, HDD and Chassis. (x9)
Screw type 2
This screw is used to lock the ODD interface board. (x2)
Installation Tools
Cross type screwdriver, can be used to do most of the installation.
Choose one with a magnetic head would be better.
Pliers, can be used as an auxiliary tool to connect some connec-
tors or cables.
Forceps, can be used to pick up tiny screws or set up the
jumpers.
Rubber gloves, can prevent yourself from being incised and
suffering the static charge.
The built-in mainboard is designed for Media Live only. Except the mainboard, the built-
in components of the barebone include Power Supply and 8 other cards. In this chapter
we’ll show you how to install Optical Disk Drive(ODD), Hard Disk Drive(HDD), PCI Card,
CPU, CPU Cooler and Memory Modules.
