3-7
System Assembly
Follow the direction arrow to insert the
HDD into the HDD holder carefully and
then lock up the two screws (screw
type 1) with a screwdriver.
Install the HDD holder (with HDD) onto
the chassis carefully and connect the
power cable.
1 2
Connect the SATA cable and lock back
the two screws (screw type 1) on the
front panel with a screwdriver.
1
2
To Next Page
