Starter and Charging System
61
22. Remove the bushing from the clutch/pinion cover.
See Figure 6.16.
NOTE: A blind hole bearing puller with a 11mm arbor or an
screw extractor can be used.
23. Drive the rotor upper bearing out of the clutch/pinion
cover using a flat tipped punch.
See Figure 6.17.
Figure 6.16
Screw extractor
Figure 6.17
rotor upper bearing
