EXAMPLE, BCD Switch Settings
NOTE:
To configure a negative setpoint value: S6 ≥ 5.
SP1 = + 7.565 V SP2 = - 9.480 V
S1 = 5 S1 = 0
S2 = 6 S2 = 8
S3 = 5 S3 = 4
S4 = 7 S4 = 9
S5 = 0 S5 = 0
S6 = 0 S6 = 9
