2. Specifications
2.1 MK292 Digital Output Module Specifications
Parameter Specification
Input Voltage: 24 Vdc (-15%/+20%); Ripple: < 5%
NOTE:
An additional 5V power supply is required for the optional TTL level outputs;
dual power supply (24/5 Vdc) is available from MTS, P/N 380066
Current Draw: 250 mA maximum
Input Requirement: SE-based Temposonics LP with start/stop output*
Temposonics II with PWM or start/stop output
Temposonics L Series with PWM or start/stop output*
Output Format: (Selectable): Up to 24 bit:
• BCD
(maximum stroke length with BCD output scaled in millimeters is 7500 mm. When utilizing
inches, strokes may be up to 300 inches)
• Natural Binary
• Gray Code
Resolution: 0.002 in. (0.05 mm) with start/stop input
0.0002 in. (0.005 mm) with PWM input
Update Frequency: Stroke and resolution dependent
Optional Analog (Recorder) Output :Range: -10 to +10 Vdc
(used for recording; option board required - must be specified upon initial order)
12 bit resolution
5mv ripple
Fully adjustable
Programming Parameters: Zero
Resolution
Stroke Length
Measuring Direction
Analog Output
(used for recording; option board required - must be specified upon initial order)
Operating Temperature: 0 to 60°C (32 to 140°F)
Connection: 64 pin edge connector (DIN 41612; provided with circuit card)
Cable Requirements: 8 x 24 AWG, twisted pairs, shielded low capacitance cable (BELDEN 8105 or equivalent)
w/appropriate number of conductors for sensor used
Maximum Cable Length: Sensor with RS422 output: 500 meters (1640 ft.)
Sensor with PWM output: 152.4 meters (500 ft.)
Dimensions: MK292 Card, Front Panel: 30.2 x 128.4 mm (1.19 x 5.06 in.)
MK292 Module, Front Panel: 50.4 x 128.4 mm (1.98 x 5.06 in.)
* When using the MK292 with a Temposonics LA or LP sensor, please contact Applications Engineering.
Specifications are subject to change without notice. Consult MTS for verification of specifications critical to your application.
3
