2.2 Temposonics Position Sensor Specifications
For detailed specifications and installation requirements for the position sensors, refer
to the appropriate document, as follows:
• Temposonics II Sensor Installation and Instruction Manual (P/N 550055)
• SE-based Temposonics LP Installation Guide (P/N 550582)
• Temposonics L Series/Digital Product Specification (P/N 550539)
Parameter Specification
Input Voltage: Powered from MK292 Module
Stroke Length: Temposonics II: Up to 300 inches (7620 mm)
SE-based Temposonics LP: Up to 48 inches (1219 mm)
Temposonics L Series: Up to 120 inches (3048 mm)
Non-linearity: Temposonics II: < ± 0.05% of full scale or ± 0.002 inch (±0.05 mm), whichever is greater
SE-based Temposonics LP: ± 0.1% of full scale or ± 0.004 in. (± 0.10 mm), whichever is greater
Temposonics L Series: 0.03% of full scale
Repeatability: ± 0.001% of full scale or ± 0.0001 inch (± 0.002 mm), whichever is greater
Operating Temperature: Head Electronics: - 40 to 150°F (- 40 to 66°C)
Sensor Rod: - 40 to 185°F (- 40 to 85°C)
Operating Pressure: Temposonics II Rod-Style Sensors: 3000 psi continuous, 8000 psi static typical
Temposonics L Series Rod-Style Sensors (Model LH): 5000 psi continuous, 10,000 psi static
Outputs (absolute): Start/stop or PWM configured for
external
interrogation
Mounting Distances: Sensor with RS422 output to MK292: 500 meters (1640 ft.)
Sensor with PWM output to MK292: 152.4 meters (500 ft.)
MK292 to PLC: 25 meters (82 ft.)
Specifications are subject to change without notice. Consult MTS for verification of specifications critical to your application.
NOTE (Zero Points):
Before ordering an MK292 with a Temposonics LA
or LP sensor, consult an MTS Sensors Division
Applications Engineer for details regarding the
positioning of the sensor’s ZERO point.
4
