2.2 Lifting specifications
Lifting specifications
DANGER
Suspended load.
Danger to life!
• Use appropriate lifting devices and appliances.
• Never stand beneath a suspended load.
Applies also to 16V4000Cx0, 16V4000Cx1
1 Max. permissible diagonal
pull: 10°
2 Center of gravity
Take note of the engine center of gravity
Refer to the installation/arrangement drawings for details of the center of gravity of the system or the center
of gravity of the engine/generator.
18 | Transport |
MS150049/04E 2017-04
TIM-ID: 0000076084 - 001
