4.7 Engine – Main dimensions

Engine model Length (A) Width (B) Height (C)

12V4000Cxyz approx. 2540 mm approx. 1630 mm approx. 2050 mm

16V4000Cxyz approx. 3010 mm approx. 1630 mm approx. 2050 mm

44 | Technical Data | MS150049/04E 2017-04

TIM-ID: 0000002136 - 005
