8.7.2 Injector – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Installation and removal jig
F6794703 1
Milling cutter
F30452739 1
Slotted screwdriver
F30452578 1
Torque screwdriver, 1–5 Nm
F30452774 1
Torque wrench, 10–60 Nm
F30452769 1
Torque wrench, 60–320 Nm
F30452768 1
Assembly compound (Optimoly Paste White T)
40477 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Engine oil
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
NOTICE
Cable damage during operation.
Fire hazard!
• Twist the cables when attaching.
• Ensure that the cables do not touch any components.
NOTICE
Removing all injectors.
Component damage possible!
• Ensure that the HP accumulator is secured on the engine through two HP lines.
Preparatory steps
1. Close off fuel supply to engine.
2. Remove cylinder head cover (→ Page 94).
MS150049/04E 2017-04
| Injector | 97
TIM-ID: 0000000952 - 013
