8.5 Valve Drive
8.5.1 Valve gear – Lubrication
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Engine oil
Valve gear – Lubrication
1. Remove cylinder head covers (→ Page 94).
2. Fill oil chambers of valve bridges with oil.
3. Fill oil chambers of rocker arms and adjusting
screws with oil.
4. Install cylinder head covers (→ Page 94).
MS150049/04E 2017-04 | Valve Drive | 87
TIM-ID: 0000000921 - 010
