3. Install the holders (7) on both sides of the crankcase (12) with screw (9) and washer (8). Tighten screw (9).
Name Size Type Lubricant Value/Standard
Screw Tightening torque (Engine oil) 290Nm +20 Nm
4. To allow the holders (3) to be secured on each side of the flywheel (2), the corresponding screws and wash-
ers must be removed from the driving end.
5. Leave the unscrewed screws with washers on engine and screw back in when the transport locking device
has been removed.
6. Place screw (6) in the recess of holder (3) and insert through the opening at the flywheel housing (1). Secure
holder (3) with screw (5) and washer (4) to flywheel (2). Tighten screw (5).
Name Size Type Lubricant Value/Standard
Screw Tightening torque (Engine oil) 180Nm +18 Nm
7. Fit conical spring washer (10) on screw (6) and tighten nut (11).
Name Size Type Lubricant Value/Standard
Nut Tightening torque (Engine oil) 27Nm +3 Nm
MS150049/04E 2017-04 | Transport | 23
TIM-ID: 0000040576 - 001
