7.8 Fuel System
7.8.1 HP fuel line – Pressure pipe neck replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Open end socket wrench
F30025897 1
Crowfoot box wrench
F30027425 1
Crowfoot box wrench
F30027424 1
Double-head box wrench
F30011450 1
Ratchet adapter
F30027340 1
Grease (Kluthe Hakuform 30-10/emulsifier)
X00029933
Engine oil
Pressure pipe neck
(→ Spare Parts Catalog)
WARNING
Fuels are combustible.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
WARNING
Compressed air
Risk of injury!
• Do not direct compressed-air jet at persons.
• Wear protective goggles / safety mask and ear protectors.
Preparatory steps
1. Remove cylinder head cover (→ Page 178).
2. Drain fuel (→ Page 192).
190 | Task Description | MW15550/06E 2012-02
TIM-ID: 0000004678 - 005
