Sentry II with Water Works Box Operating Instructions Effective April 1, 2000
Part No. 8823728 Revised November 10, 2003
9.19 Label No. 8822972, Transformer Wiring
9.20 Label No. 8822705, Canadian and U.S. Certification
9.21 Label No. 8823729, 24 VAC and 240 VAC Component List
9.22 Label No. 8820409, Mueller Name Tag
57
240V 208V COM
X4 X2 X3 X1
H1
H2
®
DAIRY FARM EQUIPMENT
®
DAIRY FARM EQUIPMENT
9910 8822972
Standard Transformer
Part No. 8822971 (240V)
Japanese Transformer
Part No. 8823060
(195V)
24V
24V
195V
240V
NRTL /C
LR67608
NPI
8822705
3 Remote Alarm Lamp (24 VAC)
4 Remote Cool Lamp (24 V
AC)
5 Remote Wash Lamp (24 V
AC)
6 Condensing Unit 1 (24 V
AC)
7 Condensing Unit 2 (24 V
AC)
8 Drain Valve (24 V
AC)
9 Hot Water Solenoid (24 V
AC)
10 Cold Water Solenoid (24 V
AC)
2 Neutral (24 V
AC)
11 Pressure Switch (N.O.)
12 Pressure Switch (N.O.)
13 Detergent Solenoid (24 VAC)
14 Acid Solenoid (24 VAC)
15 Not Used —
16 Pump Motor (240 VAC)
17 Pump Motor (240 VAC)
18 Agitator Motor (240 VAC)
19 Agitator Motor (240 VAC)
L1 Main Power (240 VAC)
L2 Main Power (240 VAC)
0004 8823729
8820409
