MULTILIFT Ultima S Flex - Page 177

177
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
>>>
ERROR CODE
COMMENTS / PROBLEM LOCATION
PROGRAM DESCRIPTION POSSIBLE ACTION CONSEQUENCE
d009
MIDDLE FRAME IS UP (NOT NEARLY DOWN)
MIDDLE FRAME IN WRONG POSITION
d010
MIDDLE FRAME IS DOWN
MIDDLE FRAME IN WRONG POSITION
d011
MIDDLE FRAME IS NEARLY DOWN
MIDDLE FRAME IN WRONG POSITION
d012
REAR FRAME IS UP (NOT DOWN)
REAR FRAME IN WRONG POSITION
d013
REAR FRAME IS DOWN
REAR FRAME IN WRONG POSITION
d014
ARM IS NOT IN BACK POSITION
TELESCOPIC / TILTING ARM IN WRONG
POSITION
SLIDE / TILT BWD OR CHECK THE HORIZONTAL
MOVEMENT BACK SENSOR
d015
ARM IS IN BACK POSITION
TELESCOPIC / TILTING ARM IN WRONG
POSITION
d016
PULL LIMITER IS ACTIVE
PULL LIMITER IS ACTIVE SLIDE / TILT BWD OR CHECK THE PULL LIMITER
SENSOR
NO SLIDE FWD
d017
CRANE BODY IS ACTIVE
CRANE BODY ON IS ACTIVE SLIDE / TILT BWD OR CHECK THE CRANE BODY
SENSOR
NO SLIDE FWD
d018
CATCH LOCKING RIGHT ARE ACTIVE
CATCH LOCKING RIGHT ARE ACTIVE OPEN THE RIGHT SIDE CATCH LOCKING / CHECK
THE SENSOR
NO HOOKLIFT
FUNCTION
