MULTILIFT Ultima S Flex - Diagnostic codes (Diagnoses)

176
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
>>>
ERROR CODE
COMMENTS / PROBLEM LOCATION
PROGRAM DESCRIPTION POSSIBLE ACTION CONSEQUENCE
DIAGNOSES
d000
BODYLOCKS ARE OPEN
BODYLOCKS IN WRONG POSITION CLOSE THE BODYLOCKS NO HOOKLIFT FUNCTION
d001
BODYLOCKS ARE CLOSED
BODYLOCKS IN WRONG POSITION OPEN THE BODYLOCKS NO HOOKLIFT FUNCTION
d002
BODYLOCKS ARE IN MIDDLE POSITION
BODYLOCKS IN WRONG POSITION OPEN/CLOSE THE BODYLOCKS OR CHECK
SENSORS
d003
TIPPING LOCK IS OPEN
TIPPING LOCK IN WRONG POSITION CHECK THE TIPPING LOCK CLOSED SENSOR /
OPEN THE LOCKS / SLIDE FWD
NO HOOKLIFT FUNCTION
d004
TIPPING LOCK IS CLOSED
TIPPING LOCK IN WRONG POSITION CHECK THE TIPPING LOCK CLOSED SENSOR /
CLOSE THE LOCKS / SLIDE BWD
NO HOOKLIFT FUNCTION
d005
TIPPING LOCK IS IN MIDDLE POSITION
TIPPING LOCK IN WRONG POSITION CHECK SENSORS
d006
REAR FRAME IS UP (NOT DOWN)
TIPPING LOCK IN WRONG POSITION
d007
TIPPING LOCK IS CLOSED
TIPPING LOCK IN WRONG POSITION
d008
MIDDLE FRAME IS UP (NOT DOWN)
MIDDLE FRAME IN WRONG
POSITION
