MULTILIFT Ultima S Flex - Page 31

31
Ultima S / SL Flex & Pro
3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
OPEN
Button Second LED
comes on
6. Open the hydraulic body locks
- press the BODY LOCK button
- LOCKS NOT CLOSED signal light lit on the control unit when the locks are
open.
Open the mechanical or hydraulic front locks (optional).
7. Move the hook arm fully rearward position
- move the CONTROL LEVER to left and back (2GCC)
- press the HOOK ARM BACK button (2GMR and 2GRC)
- start at idle and increase the engine speed gradually.
Mechanical tipping lock will be opened in the rear position of the hook arm.
Move the Two LEDs Button
control lever are on
to left and
back
