MULTILIFT Ultima SL Flex - Page 158

158
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
Мin 45 mm
Мin 65 mm
Мin 80 mm
Мin 63 mm
Мin 82 mm
Мin 98 mm
Мin 70 mm
Мin 40 mm
Мax 90 mm
Мax 92 mm
Мax 80 mm
s min 54 mm
s min 54 mm
Ultima S / SL std. Ultima S / SL DE
Ultima S / SL SE
s =
60 mm
s =
60 mm
30 mm
100 mm
s =
60 mm
Мin 70 mm
Мin 55 mm
Мin 71 mm
Мin 10 mm
Мax 100 mm
Ultima S / SL pneum.
Мin 2.17 in (55 mm)
Мax 3.94 in
(100 mm)
Мin 0.39 in (10 mm)
Ultima S / SL pneum.
s = 2.36 in (60 mm)
Мin 1.77 in (45 mm)
3.94 in (100 mm)
Мin 2.56 in
Мin 3.15 in
Мax 3.54 in
(90 mm)
Ultima S / SL std.
1.18 in (30 mm)
s min 2.3 in (54 mm)
Мin 2.80 in (71 mm)
Hook wear limits
Мin 2.17 in (55 mm)
Мax 3.94 in
(100 mm)
Мin 0.39 in (10 mm)
Ultima S pneum.
s = 2.36 in (60 mm)
Мin 1.77 in (45 mm)
3.94 in (100 mm)
Мin 2.56 in
Мin 3.15 in
Мax 3.54 in
(90 mm)
Ultima S std.
1.18 in (30 mm)
s min 2.3 in (54 mm)
Мin 2.80 in (71 mm)
