MULTILIFT Ultima SL Flex - Main Components

7
Ultima S / SL Flex & Pro
3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
4
1
2
3
5
6
7
8
9
Main components
1. Gripping hook and hook arm
2. Middle frame
3. Body locking, mechanical and hydraulic
4. Rear frame
5. Rear rollers
6. Sub-frame
7. Main cylinders
8. Sliding cylinder
9. Body locking cylinder
Due to continuous product development some picture details may look di󰀨erent when
compared to the actual device.
