157
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
General inspection
Check:
• steel construction for deformations and breakages
• hooklift fastening to the truck chassis, for breakages and loose bolts
• fastening of the rear rollers. Check the securings of all shafts.
• surfaces of piston rods. If the chromium surface of the rod is damaged, especially if
the scratches are longitudinal, the rod or the whole cylinder must be changed.
• wear rate of the gripping hook. The original thickness of the hook must not be worn
more than 10 %.
• wear rate of the slide pads. The maximum wear of the slide pads is 0.12 in (3 mm),
but already a clearance of over 0.04 in (1 mm) between the hook arm and the
middle frame requires adding of space plates or replacement of slide pads.
See the picture on the following pages.
