MULTILIFT Ultima SL Flex - Lowering the Tipping Device

46
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
Lowering the tipping device
12. Lower the tipping device
- move the CONTROL LEVER forwards (2GCC)
- press MAIN CYLINDERS FORWARD button (2GMR and 2GRC)
- the indicator light FRAME NOT DOWN goes o󰀨 as the middle frame is
lowering onto the subframe.
13. Check that the frame of the Ultima equipment and the container are in the
lowest position.
14. Close the container tail gate.
Also close the mechanical or hydraulic front locks (optional).
Move the Second
control LED Button
lever goes
forward out
