MULTILIFT Ultima SL Flex - Page 180

180
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
>>>
FAULTS
03.00
LOW ILLEGAL
VOLTAGE
DIGITAL
OUTPUT
(OUTPUT
1 - 4)
DIGITAL OUTPUT
(1-4) HAVE
ILLEGAL VOLTAGE,
EXPECTED LOW
DETECTED AS
HIGH.
ERROR DISPLAYED ON DISPLAY.
04.00
LOW SHORT
CIRCUIT
ON DIGITAL
OUTPUT
DIGITAL OUTPUT
(1 - 4) SHORT
CIRCUITED OR
OVERLOADED, CAN
BE ANY OF THE 4
OUTPUTS.
ERROR DISPLAYED ON DISPLAY.
08.01
MEDIUM CAN PASSIVE CAN BUS IN
PASSIVE MODE.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
08.02
MEDIUM CAN I/O
BUFFER
OVERFLOW
CAN OVERRUN;
EITHER THE CAN
INPUT OR CAN
OUTPUT BUFFER
ARE FULL.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
08.03
MEDIUM CAN
PHYSICAL
LAYER
ERROR
BAD
COMMUNICATION /
TRANSMISSION.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
08.04
MEDIUM CAN
MESSAGE
LENGTH
ERROR
CAN MESSAGE
LENGTH IS TOO
LONG.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
08.05
MEDIUM CAN
MESSAGE
LENGTH
ERROR
CAN MESSAGE
LENGTH IS TOO
SHORT.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
08.06
MEDIUM CAN
TRANSMIT
COLLISION
TO MANY
COLLISIONS ON
CAN-BUS.
ERROR DISPLAYED ON DISPLAY, CAN MODULE
SWITCHED TO PRE-OPERATIONAL STATE AND
SYSTEM WILL SELF RESET AUTOMATICALLY.
WAIT, UNTIL THE SYSTEM HAS STARTED.
ERROR
CODE
1.2 (CATEGORY)
DESCRIPTION CAUSE ACTION
