MULTILIFT Ultima SL Flex - Page 185

185
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
Ultima S / SL
*) It is recommended to use a drying material,
for example teon or a silicon spray.
1 - 8 Note! Use LITHIUM based general lubrication grease (EP2)
or biodegradable lubricant NLGI 2.
It is not allowed to use a graphite or molybdensulde based lubricant.
Point Lubrication point Number
of nipples
1 Main cylinder lower fastening 1 + 1
2 Main cylinder upper fastening
as well as lifting rollers (additional equipment)
1 + 1
1 + 1
3 Tipping lock shafts 1 + 1
4 Middle frame bearing (under the rear frame) 1 + 1
5 **) Middle frame bearing (on the rear tube of the middle frame)
Only Ultima 26S and Ultima 30S
1 + 1
6 Rear frame bearing 1 + 1
7 Rear rollers 2 + 2
8 Pull limiting shaft (accessory) 1
9 Hooks of the hydraulic locks (if necessary) spray (*
10 Hook arm slide tube (if necessary) spray (*
Total number of nipples Ultima 14S - 21S, 18SL - 24SL 16 (+3)
Total number of nipples Ultima 26S - 30S 18 (+3)
