Ultima S / SL Flex & Pro
3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
Ref. Component or function
1 CAN bus cable
2 Control panel cable
3 Control lever
a = main cylinders forward
b = main cylinders backward
c = telescopic hook arm (sliding) forward
d = telescopic hook arm (sliding) backward
(e) = automatic sequence control forward / friction relief
(f) = automatic sequence control backward / friction relief
4 & 5 Button FAST SPEED *)
6 & 7 Button HOOK SAFETY LOCK
8 & 9 Button TELESCOPIC HOOK ARM FORWARD (optional to 3c)
10 & 11 Button TELESCOPIC HOOK ARM BACKWARD (optional to 3d)
12 Four digit display
13 Point: voltage OK and system OK
14 Warning light FRAME NOT DOWN
15 Warning light HYDRAULIC BODY LOCKS NOT CLOSED
16 Warning light UNDER-RUN BAR RETRACTED / BOGIE BLOCK ENGAGED
17 Warning light AUXILIARY EQUIPMENT
18 Button HYDRAULIC BODY LOCKS CLOSED
19 Button HYDRAULIC BODY LOCKS OPEN
20 - 27 Alternative function buttons according to the equipment on the Ultima
device (cf. following pages)
Control unit components and basic functions
*) Relief of horizontal movement and oating of the main cylinders can
temporarily be by-passed by a quick action switch (push button).
