MultiOne 1 Series User Manual

Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
11/49
MultiOne SRL
Ref. Part Function
1 Rear wheel It supports, steers and allows the movement of the machine.
2 Driving seat It support the operator.
3 Footrest It supports the left foot.
4 Steering wheel It allows to change direction while driving.
5 Control panel
It assembles operating controls of the machine and of the possible attachment assembled
to the machine.
6 Proportional forward and reverse pedal It allows the movement of the machine.
7 Engine It powers the hydraulic pumps.
8 Opening engine space compartment
It protects the engine and prevents the operators in charge to get in touch accidentally
with the mobile parts and high parts.
9 Lifting boom It raises the attachment assembled of the machine.
10 Hydraulic circuit hoses They allow the passage of the hydraulic oil to power the attachment.
11 Quick rapid connections They allow the connection to the attachment hydraulic circuit.
12 Quick coupler It allows the mechanic connection to attachment.
13 Front wheels (n.2) They support and allow the machine movement.
TAB. 2
DESCRIPTION OF THE MACHINE -4

MultiOne 1 Series Specifications

General

Brand	MultiOne
Model	1 Series
Category	Compact Loader
Language	English
