9.7.7 Hydraulic oil change
To change the hydraulic oil proceed as follows:
1) Raise the lifting boom.
2) Turn off the machine and secure the lifting boom in the upright position with the safety block (see par. 9.3).
3) Place under the hydraulic oil tank a suitable sized container with a capacity of at least 15 l.
4) Remove the hydraulic tank drain plug (FIG. 23 - Ref. 1), located near the left front wheel, and drain all hydraulic oil from the
machine into the container.
5) When all of the hydraulic fluid has drained out of the tank, reinstall and secure the drain plug. Make sure to inspect the drain plug
O-ring (FIG. 23 - Ref. 2) for signs of wear or damage. Replace the O-ring if any signs of damage are noted.
6) Change the oil filter (see par. 9.7.6).
7) Remove the cap of hydraulic oil tank.
8) Refill the hydraulic oil tank with recommended hydraulic oil - 0280 PAKELO HYDRAULIC EP AL ISO 46.
9) Check the hydraulic oil level (see par. 9.7.5).
10) Turn on the machine (see par. 8.3.2) for a few of minutes, in this way the oil flows inside the circuit oil.
11) Turn off the machine (see par. 8.3.7).
12) Check again the hydraulic oil level (see par. 9.7.5).
ATTENTION
THE USED OIL AND FILTER MUST BE DISPOSED OF IN ACCORDANCE TO THE LAWS IN FORCE IN THE COUNTRY WHERE THE
MACHINE IS USED.
FIG. 23
2
1
MAINTENANCE -9
