Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
18/49
4- DESCRIPTION OF THE MACHINE
4.8 Hydraulic flow/engine speed diagram
The diagram in FIG. 6 represents the trend of hydraulic flow according to the engine’s rpm.
FIG. 6
l/min
65
60
55
50
45
40
35
30
25
20
15
10
5
0
1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400 3600 3800 rpm
ATTENTION
CHECK THE MANUAL OF ATTACHMENT USED TO REACH THE CORRECT SETTING.
4.9 Reasonable foreseeable misuse
DANGER
IT’S FORBIDDEN TO TAMPER WITH OR MODIFY IN ANY WAY THE MACHINE.
IT IS FORBIDDEN THE USE OF THE MACHINE FOR MISUSE, DIFFERENT FROM THOSE EXPECTED (SEE PAR. 4.5).
IT IS FORBIDDEN TO ASSEMBLE NON SUITABLE AND/OR NON ORIGINAL ATTACHMENTS TO THE MACHINE (SEE PAR. 6.2 AND
PAR. 6.3).
IT IS FORBIDDEN TO USE THE MACHINE TO CARRY AND/OR LIFT PEOPLE OR ANIMALS.
IT IS FORBIDDEN TO MOVE THE MACHINE KEEPING THE LIFTING BOOM, ATTACHMENT AND POSSIBLE LOAD UP.
IT IS FORBIDDEN TO MAKE STEERINGS AT HIGH SPEED.
IT IS FORBIDDEN TO MOVE AND USE THE MACHINE ON SLOPE OR UNSTABLE LAND.
IT IS FORBIDDEN THE USE OF THE MACHINE ON ROAD.
IT IS FORBIDDEN TO LIFT THE MACHINE BY MEANS OF A CRANE AND STRAPS.
IT IS FORBIDDEN TO GET OFF THE MACHINE WITHOUT HAVING TURN ON THE PARKING BRAKE, SWITCHED THE ENGINE OFF,
AND REMOVED THE IGNITION KEY.
IT IS FORBIDDEN LEANING FROM THE MACHINE IN MOTION.
IT IS FORBIDDEN TO OPERATE THE CONTROLS OF THE MACHINE FROM A POSITION OTHER THAN THE DRIVING SEAT
(SEE PAR. 8.3.3).
IT IS FORBIDDEN TO USE THE LIFTING BOOM TO MOVE ANY OBJECT DIFFERENT FROM THE ATTACHMENT SUPPLIED BY THE
MANUFACTURER.
