Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
27/49
MultiOne SRL
8.2 Checks before ignition
DANGER
BEFORE USING THE MACHINE IT IS COMPULSORY THAT AUTHORISED OPERATORS READ AND UNDERSTAND ALL PARTS OF
THIS MANUAL.
BEFORE TURNING ON THE MACHINE, THE OPERATOR MUST ALWAYS CHECK THE HYDRAULIC OIL LEVEL (SEE PAR. 8.4.3).
WARNING
IT IS COMPULSORY, BEFORE STARTING THE MACHINE, TO EXECUTE THE FOLLOWING CONTROLS.
Ref. Operations
1 Make sure the machine is undamaged in all its parts.
2 Make sure the safety systems are intact.
3 Check the fuel level.
4 Check the oil engine level (see chap. 9.8.1).
5 Check the oil level of the hydraulic circuit (see chap. 9.7.5).
6 Make sure all controls are in neutral position.
7 Make sure the throttle is POS. “snail”.
8 Make sure the parking brake is on (see par. 8.3.8).
9 Make sure it was carried out routine maintenance.
TAB. 15
8.3 Normal operations
WARNING
YOU MUST KEEP THE FOOTRESTS CLEAN FROM DEBRIS AND MUD.
8.3.1 Getting on the machine
To get on the machine proceed as follows:
1) Place your left foot on the left footrest where there is the non-slip strip.
2) Rise and sit on the seat.
3) Place your feet on the respective footrest in correspondence with non-slip strips.
8.3.1.1 Correct posture of use
The optimum posture that the operator must assume for a correct use of all the commands is as follows:
• Sitting on the seat with his back against the backrest.
• Facing towards the direction of travel.
• Left hand on the steering wheel.
• Right hand free to operate all other commands.
• Left foot resting on the footrest in correspondence with the non-slip strip.
• Right foot resting on the footrest in correspondence with the non-slip strip ready to operate the proportional forward and reverse
pedal.
OPERATION -8
