Self-moving multipurpose loader MULTIONE
1 Series
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
33/49
MultiOne SRL
8.3.9 Refuelling
When it is necessary to refuel proceeding as follows:
1) Put the machine in “safety state” (see par. 9.2).
2) Go onto place A (see FIG. 2).
3) Open the engine cover (see par. 9.4).
4) Unscrew the tank cap (FIG. 15 - Rif. 1) counterclockwise.
5) Refuelling, if necessary use a funnel to avoid spilling fuel.
6) Completed refuelling screw the fuel cap clockwise.
7) Close the engine cover.
DANGER
IT IS FORBIDDEN TO MAKE REFUELLING OPERATIONS WHILE SMOKING AND/OR NEARBY IN PROXIMITY OF FLAMES. THERE IS
FIRE AND/OR EXPLOSION DANGER.
FIG. 15
1
8.4 Functions/exceptional situations
8.4.1 Instability of the machine
It may happen that by performing a curve at high speed or by lifting a heavy load the machine is to be in a state of instability.
To avoid this situation proceed as follows:
1) Steer the machine only at low speed and with the load as close as possible to the ground.
2) Do not lift heavy loads by buckets or other attachment for lifting (see par. 4.7).
8.4.2 Overpressure in the hydraulic circuit
The machine is equipped with a system of hydraulic valves that limit the oil pressure within the circuit to avoid any damage.
In particular difficulty running it may happen to hear a hissing sound. This indicates that the valves were brought into service.
If the condition of effort should go on and this may result in damage so you will need to decrease the stress for the machine by
reducing the speed of work and/or the number of the engine rpm.
OPERATION -8
