Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
28/49
8.3.2 Starting up
DANGER
BEFORE PROCEEDING TO STARTING OF THE MACHINE MAKE SURE THAT, IN THE RADIUS OF TEN METRES THERE ARE NO
THINGS, ANIMALS OR PEOPLE WHOSE SAFETY MAY BE AFFECTED ACCIDENTALLY.
WARNING
BEFORE STARTING THE MACHINE IT IS COMPULSORY TO HAVE CARRIED OUT ALL THE CONTROLS PAR. 8.2.
BEFORE STARTING THE MACHINE IT IS COMPULSORY TO CHECK ALL THE COMMANDS ARE IN NEUTRAL POSITION AND THAT
THE PARKING BRAKE WAS INSERTED, PARTICULARLY CHECK THAT THE HYDRAULIC FLOW CONTROL LEVER OF QUICK
CONNECTIONS (FIG. 11 - REF. 1) IS IN “CENTRAL” POSITION (ATTACHMENT OFF).
BEFORE STARTING THE MACHINE MAKE SURE THE SCHEDULED MAINTANANCE WAS CARRIED OUT, PARTICULARLY CLEANING
OF THE MACHINE. MAKE SURE THERE ARE NO OBJECTS OR MATERIAL THAT PREVENT THE PROPER DRIVE CONTROL.
ATTENTION
BEFORE USING THE MACHINE, WE ADVISE TO EFFECTUATE SOME “USING TESTS” TO ACQUIRE A GRADUAL MASTERY OF THE
FEATURES OF THE MACHINE.
8.3.2.1 Cold engine starting
To start a cold engine proceed as follows:
1) Open the engine cover (see par. 9.4).
2) Rotate clockwise the depressurization valve (FIG. 10 - Ref. 1).
3) Close the engine cover and get on the machine.
4) Place the throttle in the middle position (FIG. 11 - Ref. 2).
5) Turn the key (FIG. 11 - Ref. 3) in Pos. “2” for two seconds, if the engine does not start, release the key and try again after a few
seconds. When the engine is started, the depressurization valve will reposition itself automatically to the initial position.
8.3.2.2 Hot engine starting
To start a hot engine proceed af follows:
1) Place the throttle (FIG. 11 - Ref. 2) in the middle position.
2) Turn the key (FIG. 11 - Ref. 3) in Pos. “2” for two seconds, if the engine does not start, release the key and start from step 1).
1
1
2
3
FIG. 10 FIG. 11
8- OPERATION
