Self-moving multipurpose loader MULTIONE
1 Series
MultiOne SRL
Instruction manual (Traslation of original instructions)
CM170001EN - 01.03.17 - 03 (11.07.18)
26/49
7 PRE-START INSPECTION
WARNING
IT IS COMPULSORY, BEFORE THE FIRST STARTING OF THE MACHINE, TO EXECUTE THE FOLLOWING OPERATIONS.
Ref. Operations
1 Make sure the machine is undamaged in all its parts.
2 Check the integrity of safety system (see par. 9.7.3).
3 Check the engine oil level (see par. 9.8.1).
4 Check the oil level of the hydraulic circuit (see par. 9.7.5).
5 Check the nipples and if necessary provide with greasing (see par. 9.7.8).
6 Get used to the controls and their functions.
TAB. 14
8 OPERATION
8.1 Adjustments
8.1.1 Adjustment of the driving seat
The machine is equipped with a driving seat adjustable longitudinally.
To adjust the position of the driving seat proceed as follows:
1) Sit on the seat.
2) Pull and hold pulled the lever (FIG. 9 - Ref. 1) placed under the seat on the right side.
3) Slide the seat backward or forward until you find a position suitable to your height.
4) Release the lever and move slightly the seat until you hear a sound that indicates the block in place of the seat.
ATTENTION
MODELS OF THE SEAT MAY VARY FROM COUNTRY TO COUNTRY AND IN ACCORDANCE WITH ANY SPECIFICATIONS AND
OPTIONS.
FIG. 9
7- PRE-START INSPECTION
