Muratec MFX-1950 - Sensor Trays

5-49 5-49
SENSOR TRAYS
1. Remove the Cover jam access.
2. Separate the Chassis cassette 2nd from the body, and remove the Sensor stopper from behind.
3. Remove the Sensor TRAYS while pulling up the Feeler MP.
Chassis cassette 2nd
Sensor stopper
TRAYS
Feeler MP
