Muratec MFX-3550 - Introduction to the User Guide; Machine Overview

Introduction
This chapter gives you an overview of your machine:
This chapter includes:
z
Machine overview
z
Control panel overview
z
Understanding the Status LED
z
Introducing the useful buttons
MACHINE OVERVIEW
Front view
1 Document feeder cover 12 Front door
2 Document feeder width guides 13 Document output tray
3 Document feeder input tray 14 USB memory port
4 Document feeder output tray 15 Control panel
5 Front door handle 16 Toner cartridge
6 Multi-purpose tray handle 17 Multi-purpose tray extension
7 Handle 18 Multi-purpose tray paper width guides
8 Paper level indicator 19 Scanner lid
9
O
p
tional tra
y
2
[a]
20 Scanner glass
10 Tray 1 21
Handset
[b]
11 Multi-purpose tray 22 Scanner lock switch
[a]
Optional device.
