Manual Cube67+ | System Manual
11
Cube67+: the plus is for...
Cube67+ bus nodes can control more modules, thus process more I/O signals.
It allows to use longer cables.
New IO link functionality with Cube67+ IOL (IO - link) modules.
An even better protection by intelligent load monitoring.
The proven benefits of Cube67
the I/O level is directly implemented in the machine, in the immediate proximity of sensors and
actuators, thus eliminating bulky and awkward wiring,
reduced dimensions ensure a compact and space-saving design of the machine.
Multifunctional I/Os enable free configuration of the two signals per slot, whether input, diagnostic
input or output.
Comprehensive diagnostics with detailed information on type and location of the fault or error
1.1 Explanation of the bus systems
For the descriptions of the different bus types please refer to the bus manuals.
You will find an overview in the section "Manual Overview and Layout" in this manu-
al.
