Murr Elektronik Cube67+ User Manual

Manual Cube67+ | System Manual
13
3. Configuration Notes
This chapter contains a short description of the Cube67+ system components and information that is
important during the electromechanical planning phase.
3.1 System Components
3.1.1 Product Designation Code
The components of the Cube67+ system are described in two diagrams that help to understand their
functions
Example for bus nodes:
Name
Description
CUBE67+
BN-P
Module characteristics of
the I/O range
Function
BN-P =
Profibus DP node
Product family
Fig. 2: Example Designation Code
Example for modules:
Name
Description
CUBE67+
DIO12 IOL4
E 8xM12
E = expansion module
C = compact module
Sockets
Module characteristics of
the I/O range
Product family
Fig. 3: Example Designation Code

Murr Elektronik Cube67+ Specifications

General

Brand	Murr Elektronik
Model	Cube67+
Category	Gateway
Language	English
