Manual Cube67+ | System Manual
15
3.1.3 Cube67 modules
All Cube67 modules can be operated at the Cube67+ bus node,
You will find an overview on the different Cube67 modules in the Cube67 System
Manual.
You will find an overview on the manuals in the section "Manual Overview and Lay-
out" in this manual.
Cube67 ENC2 E4xM12 Art. -No. 56753.
The Cube67 module is used especially for recording digital signal counts and encoder signals.
For more information, refer to Art.-No. 56753.
3.1.4 Cube67+modules
The "+" of the Cube67+ stands for the additional functions of these modules.
Cube67+ modules can only be operated on Cube67+ bus nodes.
The Cube67+ expansion modules feature an expansion interface for the internal system connection,
i.e. the latter can be routed to the following I/O modules. An expansion module can also be the sole or
the last module of a segment. In this case, a terminating resistor must be installed on the expansion
interface of the internal system connection (cf. chapter 4.2.6 "Terminal resistance of the internal sys-
tem connection").
Cube67+ DIO12 IOL4 E 8xM12
Cube67+ DIO4 RS232/485 E 4xM12
Cube67+ DIO12 IOL4 E 8xM12
Cube67+ DIO12 IOL4 E 8xM12
Tab. 2: Cube67+ Expansion Modules
