Manual Cube67+ | System Manual
39
Glossary
Actuator shutdown Short-circuit or overload at an output leads to the shutdown of the
output.
AI Analog input
AO Analog output
BN-P Bus Node - Profibus, bus node - Profibus
Bus-Run-LED LED that signals the bus status
Bussegment "Due to the electrical specification of the RS-485 interface, the number of
users
on an RS485 network is limited to 32 users.
If there are more than 32 Profibus users, the network must be
divided into segments by means of repeaters.
1 byte corresponds to 8 bits
Cfg F-LED LED to signal a correct/incorrect configuration
DI Digital input
DIN TH35 DIN standard mounting rail (35x15mm, 35x7.5mm).
DO Digital output.
DP Decentral Periphery. Profibus protocol for rapid cyclical
data exchange.
E/A(I/O) Input/output
EC Directive 2004/108/EC EMC Directive.
EMC Electromagnetic Compatibility
ESD Electrostatic discharge
FE Function ground
Freeze Command The input data of the slave are "frozen".
GSD The Device Master Data describes the technical features of a
Profibus product. This file is required to configure a
Profibus system and is provided by the device
